Honeycomb tub ntxhais

Tshaj nthuav dav Honeycomb Core
Kev nthuav dav ntawm honeycomb core tuaj yeem ua tiav qhov khoov loj deformation nyob rau hauv ib qho kev taw qhia, uas yog ib qho qauv nrog curvature loj thiab haum rau kev tsim thiab siv cov...
Ntau
Microporous Honeycomb Core
Microporous Honeycomb Core yog ib qho ultra-lub teeb, siab-kev ua tau zoo ntxeem tau cov khoom tsim los ntawm cov ntawv qib siab aramid fiber ntau. Los ntawm nws qhov tshwj xeeb micro- tus qauv...
Ntau
Flexible Honeycomb Core
Flexible Honeycomb Core yog ib qho kev ua haujlwm siab - cov khoom tseem ceeb uas tsim los ntawm aramid ntawv thiab phenolic resin. Nws qhov kev tsim kho tseem ceeb nyob hauv kev ua tiav qhov kev...
Ntau
Kev Lag Luam Qib Honeycomb Core
Kev Lag Luam Qib Honeycomb Core yog lub teeb yuag, siab - cov khoom siv muaj zog uas tsim los siv siab -kev ua tau zoo meta- aramid ntawv ua nws cov substrate. CNC1 industrial- qib cov khoom lag...
Ntau
Aviation Qib Honeycomb Core
CMAG tus kheej tsim CNC2 Aviation Qib Honeycomb Core yog cov khoom tseem ceeb tshaj plaws uas siv siab -kev ua tau zoo aramid ntawv raws li nws cov substrate thiab siv lub classic hexagonal qauv...
Ntau
Para-aramid Honeycomb Core
Para-Aramid Honeycomb Core yog lub teeb yuag, siab - cov khoom siv muaj zog uas tsim los siv cov txheej txheem siab heev los ntawm siab -kev ua tau zoo para- aramid (tseem hu ua KEVLAR) fiber ntau...
Ntau
Ua ntej - tsim Honeycomb Core
Ua ntej-Formed Honeycomb Core yog ib nrab- kho cov khoom tseem ceeb uas nws lub xeev ua haujlwm tshwj xeeb muaj peev xwm ua tau yooj yim tshwj xeeb thaum tsim khoom tom ntej. Nws cov txheej txheem...
Ntau

Qhov zoo ntawm aramid honeycomb

01/

Kub kub tsis kam, yog li nws tuaj yeem tsim los ntawm autoclave ntawm qhov kub siab tshaj 200 degree;

02/

Dav dav dav, los ntawm 29 txog 144 kg / cubic meter, kom ua tau raws li cov qauv tsim muaj peev xwm sib txawv;

03/

Nws muaj lub zog shear siab heev, tshwj xeeb tshaj yog piv rau cov ntaub ntawv ua npuas ncauj, ua rau nws tsim nyog rau kev siv hauv cov qauv hnyav.

04/

High toughness, siab tiv thaiv kev puas tsuaj piv rau lwm yam ntaub ntawv honeycomb core;

05/

Cov nplaim hluav taws kub hnyiab, tsis muaj pa taws, tsis muaj tshuaj lom (Ua raws li cov qauv hluav taws xob nruj tshaj plaws thiab cov pa luam yeeb toxicity rau aviation);

06/

Zoo heev creepage thiab qaug zog kev ua tau zoo, tuaj yeem siv tau ntev hauv kev thov kev thov;

07/

Tsis tshua muaj dej noo lub zog, tuaj yeem siv rau hauv qhov chaw muaj av noo;

08/

Corrosion kuj (Nws yuav tsis raug corroded los ntawm ya raws los yog lwm yam xov xwm nyob rau hauv kev sib cuag nrog nws, los yog nws yuav undergo electrochemical tshua nrog carbon fiber daim tawv nqaij zoo li hlau honeycomb);

09/

Qhov zoo tshaj plaws thermal rwb thaiv tsev thiab suab rwb thaiv tsev kev ua tau zoo, piv rau cov hlau thiab iav fiber ntau cov ntaub ntawv, nws muaj thermal rwb thaiv tsev zoo dua thiab suab rwb thaiv tsev kev ua tau zoo nyob rau hauv tib qhov hnyav, ua rau nws yooj yim dua, lub zog -txuag, thiab tus phooj ywg ib puag ncig.

10/

Yooj yim rau kev tsim thiab txheej txheem los txo cov nqi tsim khoom. Piv nrog cov hlau honeycomb, aramid honeycomb tuaj yeem khoov, ua kom yooj yim dua thiab ua haujlwm yooj yim dua.

Kev sib piv ntawm aramid honeycomb thiab cov khoom siv ib txwm muaj

Performance dimension	Aramid honeycomb core khoom	Cov khoom siv niaj hnub (xws li aluminium alloy, titanium alloy)	Cov khoom siv niaj hnub honeycomb (xws li, aluminium honeycomb, stainless hlau honeycomb)
Lub teeb nyhav	Qhov ceev yog 29-144kg / m3, qis dua li cov khoom siv hlau.	Qhov ntom ntawm aluminium alloy yog li 2700kg / m3, thiab qhov ceev ntawm titanium alloy yog li 4500kg / m3, nrog rau tag nrho qhov hnyav.	Qhov ntom ntawm aluminium honeycomb yog li ntawm 100-200kg / m3, thiab qhov ntom ntawm stainless hlau honeycomb yog siab dua thiab qhov hnyav tag nrho yog loj dua.
Lub zog	The tensile strength is 3 times that of steel, the initial modulus is more than 10 times that of polyamide fiber, and the peel strength is >3.0N / hli	Lub zog tensile ntawm aluminium alloy yog tsawg, thiab lub zog ntawm titanium alloy yog siab tab sis hnyav.	Aluminium honeycomb muaj lub zog tensile tsawg, thaum stainless hlau honeycomb muaj lub zog siab tab sis hnyav hnyav.
Nplaim retardant	Zoo nplaim taws retardancy, muaj zog corrosion kuj, haum rau hnyav ib puag ncig.	Cov nplaim retardancy ntawm aluminium alloy yog nruab nrab, thiab corrosion kuj ntawm titanium alloy yog zoo tab sis hnyav.	Aluminium honeycomb muaj cov nplaim hluav taws xob dav dav, stainless hlau honeycomb muaj corrosion kuj zoo tab sis hnyav hnyav.
Kev ua haujlwm rwb thaiv tsev	Dielectric zog Ntau dua los yog sib npaug rau 100,000 volts / mm, zoo heev rwb thaiv tsev.	Kev rwb thaiv tsev ntawm aluminium alloy tsis zoo, thiab kev rwb thaiv tsev ntawm titanium alloy yog qhov nruab nrab.	Kev rwb thaiv tsev ntawm aluminium honeycomb yog qhov tsis zoo, thiab kev rwb thaiv tsev ntawm stainless hlau honeycomb yog qhov nruab nrab.
Rov qab	Nws muaj kev ua haujlwm siab thiab tuaj yeem nqus tau lub zog zoo.	Lub resilience ntawm aluminium alloy yog nruab nrab, thiab cov resilience ntawm titanium alloy tsis zoo.	Aluminium honeycomb muaj qhov nruab nrab resilience, thaum stainless hlau honeycomb muaj tsis zoo resilience.
Electromagnetic kev ua tau zoo	Nws muaj kev ua haujlwm zoo ntawm electromagnetic yoj kis tau tus mob thiab tsim nyog rau cov khoom xws li radar npog thiab kav hlau txais xov npog.	Qhov kev ua tau zoo ntawm aluminium alloy yog qhov nruab nrab, thiab kev ua haujlwm ntawm titanium alloy tsis zoo.	Kev ua haujlwm ntawm aluminium honeycomb yog qhov nruab nrab, thiab kev ua haujlwm ntawm stainless hlau honeycomb tsis zoo.
Kub kub stability	Kub tiv taus ntau yam -196℃txog 220 degree, zoo heev-kub stability.	Aluminium alloy muaj qhov nqaim kub tsis kam, thiab titanium alloy muaj qhov kub thiab txias ruaj khov tab sis hnyav hnyav.	Aluminium honeycomb muaj qhov nqaim kub ua haujlwm ntau, thiab stainless hlau honeycomb muaj qhov kub thiab txias stability tab sis hnyav hnyav.
Corrosion kuj	Nws muaj zog corrosion kuj thiab tuaj yeem tiv taus qhov kev txiav txim ntawm roj, hydraulic roj, thiab lwm yam xov xwm yam tsis muaj kev puas tsuaj.	Lub corrosion kuj ntawm aluminium alloy yog nruab nrab, thiab corrosion kuj ntawm titanium alloy yog zoo tab sis hnyav.	Kev tiv thaiv corrosion ntawm aluminium honeycomb yog qhov nruab nrab, thiab corrosion kuj ntawm stainless hlau honeycomb zoo dua tab sis hnyav.
Kev tiv thaiv ib puag ncig	Tsawg formaldehyde tso tawm (tsawg dua los yog sib npaug rau 0.05mg / m3), ua tau raws li cov kev cai ntawm kev lag luam niaj hnub rau cov ntaub ntawv ib puag ncig.	Aluminium alloy thiab titanium alloy feem ntau yog ib puag ncig tus phooj ywg, thiab qee cov khoom siv ib txwm muaj cov khoom tsis zoo.	Aluminium honeycomb thiab stainless hlau honeycomb feem ntau yog ib puag ncig tus phooj ywg, thiab qee cov khoom siv ib txwm muaj cov khoom tsis zoo.

Jiaxing CMAG Composite Material Co., Ltd. yog ib qho ntawm cov ua honeycomb core manufacturers thiab lwm tus neeg nyob hauv Suav teb. Peb sov siab txais tos koj rau cov lag luam wholesale siab - qib honeycomb core los ntawm peb lub hoobkas. Tag nrho cov kev cai tsim khoom yog nrog cov khoom zoo thiab cov nqi sib tw.
